PRC 1000 6 COLUMN Palletizer


Speed Icon.jpg

UP TO 1000 CYCLES/H
HIGH SPEED

Features Icon.jpg

HIGHLIGHTS
High Production and Layer Compaction


Robotic palletizer with top loading, based on a structure with 6 load-bearing columns with electro-mechanical pallet lift. It is distinguished by its particular strength, versatility and high production speed.

The precision and flexibility of bag positioning, typical of robots, merges with a compacting capacity and the speed of a traditional "layered" palletizer.

The finished pallet results extremely compact since the bags can be pressed vertically and horizontally.

The use of cutting edge brushless motors and drives make this palletizer fast and reliable. The electronics used allow any type of layer to be made. The simplified and user-friendly management software allow also less expert operators to quickly change the work program, and even change the palletizing pattern to adapt it to various needs.


BAG / BOX DIMENSION
min. 200 x 200 mm
Max. 550 x 1100 mm

BAG / BOX TYPES
Various

OPTIONS
Bag flattening, square roller conveyor, printing, pallet loader, wrapping in place, loaded pallet discharge.


FEATURES AND BENEFITS

There are many reasons to choose our products:

  • 01 Automatically adapts to different formats simply and quickly.

  • 02 All of the axes are moved by brushless motors.

  • 03 Lateral and vertical presses of the bag layer

  • 04 Possibility of processing 800 x 1200 mm and 1000 x 1200 mm pallets

  • 05 Maximum pallet height 2000 mm

  • 06 Automatic control of the correct operating cycle

  • 07 Integrated security and access control system

  • 08 Fall arrest and anti-collision against gripping system safety device

  • 09 Touch-screen operator panel

  • 10 Self-diagnosis system for anomalies and verification via display


PRC 1000 Palletizer.png
